Compactor Feeding Type Pelletizing Machine
The compactor type granulation production line is suitable for a wide range of plastic films, including PP, PE, and BOPP. Inside the compactor, raw materials undergo crushing and compaction, slight melting, and moisture evaporation. It comprises a reduction gearbox, screw, barrel, vacuum system, water ring die-face hot-cutting system, and vibrating drying system. The cutting speed of the water ring die is adjustable via frequency conversion control. The vibrating drying system integrates a dehydration vibrating screen with horizontal centrifugal dehydration to yield high-quality plastic pellets.
| Model | Screw Diameter | Screw L/D | Main Motor Power | Capacity |
|---|---|---|---|---|
| SJ85-33 | 85mm | 33:1 | 55KW | 150-200kg/hr |
| SJ100-33 | 100mm | 33:1 | 90KW | 200-300kg/hr |
| SJ130-33 | 130mm | 33:1 | 132KW | 300-400kg/hr |
| SJ160-33 | 160mm | 33:1 | 160KW | 400-600kg/hr |
| SJ180-33 | 180mm | 33:1 | 250KW | 600-1000kg/hr |
Our machinery is engineered to dispose of and recycle various types of waste materials including:
